Round up log debarker features:
1. This log debarker adopts rotary cutting principle of spindleless veneer lathe, it can quickly and effectively remove the bark.
2. Feeding with hydraulic controlling, coupled with self-balance design.
3. Small rotation spindle is equipped, which can help the debarker to work with bend log.
4. Working length is optional for customers (4 ft & 6 ft & 8ft)
5. Knife-gap auto change during the debarking process
6. Maximum working diameter can be customized.
Specification:
Model | BBP2600F1 | BBP2600G | BBP2000F1 | BBP2000G | BBP1400F1 | BBP1400G |
Working log diameter: mm | 80~400 | 130~500 | 80~400 | 130~500 | 80~400 | 130~500 |
Maximum working length: mm | 2600 | 2600 | 2000 | 2000 | 1400 | 1400 |
Motor power: kw | 37.7 | 37.7 | 37.7 | 37.7 | 22.7 | 22.7 |
Cutting speed: m/min | 60 | 60 | 60 | 60 | 60 | 60 |
Overall dimension: mm | 3850x2100x1400 | 3850x2200x1500 | 3450x2100x1400 | 3450x2200x1500 | 2800x2100x1400 | 2800x2200x1500 |
Weight: kg | 7800 | 8000 | 6800 | 7000 | 6200 | 6500 |
We accept customize service, such as change the working diameter or length, more information, please contact us freely.
Round up log debarker features:
1. This log debarker adopts rotary cutting principle of spindleless veneer lathe, it can quickly and effectively remove the bark.
2. Feeding with hydraulic controlling, coupled with self-balance design.
3. Small rotation spindle is equipped, which can help the debarker to work with bend log.
4. Working length is optional for customers (4 ft & 6 ft & 8ft)
5. Knife-gap auto change during the debarking process
6. Maximum working diameter can be customized.
Specification:
Model | BBP2600F1 | BBP2600G | BBP2000F1 | BBP2000G | BBP1400F1 | BBP1400G |
Working log diameter: mm | 80~400 | 130~500 | 80~400 | 130~500 | 80~400 | 130~500 |
Maximum working length: mm | 2600 | 2600 | 2000 | 2000 | 1400 | 1400 |
Motor power: kw | 37.7 | 37.7 | 37.7 | 37.7 | 22.7 | 22.7 |
Cutting speed: m/min | 60 | 60 | 60 | 60 | 60 | 60 |
Overall dimension: mm | 3850x2100x1400 | 3850x2200x1500 | 3450x2100x1400 | 3450x2200x1500 | 2800x2100x1400 | 2800x2200x1500 |
Weight: kg | 7800 | 8000 | 6800 | 7000 | 6200 | 6500 |
We accept customize service, such as change the working diameter or length, more information, please contact us freely.
